7 Parameterisation of the Operating Modes
NOTe
The current limitation is defined via parameters 0x38 - 0x3B. The values of the parameters 0x38 - 0x3B must be the
same if the maximum current characteristic is used. If the operational quadrants are changed there are no jumps in the
current limitation.
The speed values Y0…Y4 are given in %.
X values: Target value analog IN A1: 0 – 10 V corresponds 0 – 1023.
Target value PWM IN 1: 0 – 100 % corresponds X value 0 – 100.
Target value frequency IN 1: lower cut-off frequency (Parameter 0x3D) corresponds X value 0.
Target value frequency IN 1: upper cut-off frequency (Paramete r 0x3E) corresponds X value 1023.
These are defined via:
P 38 – I_Max_driving_rh
P 39 – I_Max_driving_lh
P 3A – I_Max_braking_rh
P 3B – I_Max_braking_lh
