78
8 Inputs and Outputs
8.1.2 Input IN 1 and Input IN 2
Parameter 0x1: Mode 1 (for IN 1)
Description: The parameter Mode 1 contains the configuration for the IN 1. This parameter describes how this is to be used and which
control task it undertakes.
Default value: 1: Fixed speed N1 or dyn. target speed
Scaling:
1: Fixed speed N1 or dynamic target speed selectable via IN 1
2: Changeover to dyn. current limitation with A1 via IN 1
3: Travel distance with IN 1
4: Teach with IN 1
5: A-Logic with IN 1
6: Change direction of rotation with IN 1
7: PWM via IN 1
8: Frequency via IN 1
9: RS485 mode without IN 1 and IN 2
Dependencies: Input IN 2 parameter
Parameter 0x2: Mode 2 (for IN 2)
Description: The parameter Mode 2 contains the configuration for the IN 2. This parameter describes how this is to be used and which
control task it undertakes.
Default value: 1: Fixed speed N2
1: Fixed speed N2 or dynamic target speed selectable via IN 2
2: Changeover to dynamic current limitation with dyn. target value via IN 2
3: Travel distance with IN 2
4: Teach with IN 2
5: Teach with IN 2
6: Direction rotation reverse with IN 2
7: Analog input IN 2 as dyn. current limitation
8: Brake to IN 2 (drive may only rotate if brake released)
Dependencies: Input IN 1 parameter
