7 Parameterisation of the Operating Modes

7.25 Operating mode 67: Rotational direction; dynamic current limit via a2

NOTe

In order for the parameter to function, KP_H must be > 0.

Function IN 1:

Selecting the rotational direction.

Function IN 2:

Analog A2 dynamic current limitation.

Speed

Current limit

IN A

IN B

IN 1

IN 2

Direction

Value

Type

Value

Function

Comment

0

0

x

A2

-

0

-

-

Free-wheeling

No braking, no current feed

1

0

0

A2

pos

A1

D

A2

N control

1

0

1

A2

neg

A1

D

A2

N control

1

0

0

A2

pos

A1

D

A2

N control

1

0

1

A2

neg

A1

D

A2

N control

0

1

0

A2

neg

A1

D

A2

N control

0

1

1

A2

pos

A1

D

A2

N control

0

1

0

A2

neg

A1

D

A2

N control

0

1

1

A2

pos

A1

D

A2

N control

1

1

0

A2

-

0

D

A2

Stop

Braking and stopping

1

1

1

A2

-

0

D

A2

Stop

Braking and stopping

1

1

0

A2

-

0

D

A2

Stop

Braking and stopping

1

1

1

A2

-

0

D

A2

Stop

Braking and stopping

Stop control =

If KP_H > 0; brake and stop in the current position on changeover to IN A = IN B = 1 + Coasting rh, lh.

If KP_H = 0; brake and stop on changeover to IN A = IN B = 1, run speed to 0.

S = Static
P = Parameter
F = Freeze
D = Dynamic
x = Arbitrary value
