7 Parameterisation of the Operating Modes
7.27 Operating mode 71: Speed setpoint PWM, N2
NOTe
In order for the parameter to function, KP_H must be > 0.
Function IN 1: Input for PWM signal.
Function IN 2: Selection of the speed setpoint source PWM / parameter.
Speed Current limit
IN A IN B IN 1 IN 2 Direction Value Type Value Function Comment
0 0 x x - 0 - - Free-wheeling No braking, no current feed
1 0 PWM 0 pos PWM S P N control
1 0 PWM 0 pos PWM S P N control
1 0 PWM 1 pos N2 S P N control
1 0 PWM 1 pos N2 S P N control
0 1 PWM 0 neg PWM S P N control
0 1 PWM 0 neg PWM S P N control
0 1 PWM 1 neg N2 S P N control
0 1 PWM 1 neg N2 S P N control
1 1 PWM 0 - 0 S P Stop Braking and stopping
1 1 PWM 0 - 0 S P Stop Braking and stopping
1 1 PWM 1 - 0 S P Stop Braking and stopping
1 1 PWM 1 - 0 S P Stop Braking and stopping
Stop control = If KP_H > 0; brake and stop in the current position on changeover to IN A = IN B = 1 + Coasting rh, lh.
If KP_H = 0; brake and stop on changeover to IN A = IN B = 1, run speed to 0.
S = Static
P = Parameter
F = Freeze
D = Dynamic
x = Arbitrary value
