7 Parameterisation of the Operating Modes
7.18 Operating mode 37: Distance; dynamic current limit a2
NOTe
In order for the parameter to function, KP_H must be > 0.
Function IN 1:
Travel distance; the distance increases with each high flank (x); displacement = x*distance.
Function IN 2:
Analog A2 dynamic current limitation.
Speed
Current limit
IN A
IN B
IN 1
IN 2
Direction
Value
Type
Value
Function
Comment
0
0
x
A2
-
0
-
-
Free-wheeling
No braking, no current feed
1
0
x
A2
pos
A1
D
A2
N control
1
0
x
A2
pos
A1
D
A2
N control
1
0
x
A2
pos
A1
D
A2
N control
1
0
x
A2
pos
A1
D
A2
N control
0
1
x
A2
neg
A1
D
A2
N control
0
1
x
A2
neg
A1
D
A2
N control
0
1
x
A2
neg
A1
D
A2
N control
0
1
x
A2
neg
A1
D
A2
N control
1
1
0
A2
-
0
D
A2
Stop
Stopping
1
1
0 -> 1
A2
-
A1
D
A2
Distance
Positioning
1
1
0
A2
-
0
D
A2
Stop
Stopping
1
1
0 -> 1
A2
-
A1
D
A2
Distance
Positioning
Distance =
Parameter 44 + 45; relative distance with plus/minus sign. Positive distances are travelled in a clockwise direction.
Travel distance only if KP_H > 0
For further information,
.
Stop control =
If KP_H > 0; brake and stop in the current position on changeover to IN A = IN B = 1 + Coasting rh, lh.
If KP_H = 0; brake and stop on changeover to IN A = IN B = 1, run speed to 0.
S = Static
P = Parameter
F = Freeze
D = Dynamic
x = Arbitrary value
