10 Parameter Description
Parameter 0x17: Fixed speed N1
Description: Fixed speed value, which is used depending on the setting of the parameter 0x1 and parameter 0x2 and their corresponding inputs IN 1 / IN 2.
Parameter 0x18: Fixed speed N2
Description: Fixed speed value, which is used depending on the setting of the parameter 0x1 and parameter 0x2 and their corresponding inputs IN 1 / IN 2.
Parameter 0x19: Fixed speed N3
Description: Fixed speed value, which is used depending on the setting of the parameter 0x1 and parameter 0x2 and their corresponding inputs IN 1 / IN 2.
Parameter 0x1A: t ramp-up cw
Description: Parameter is to be seen and used as the ramp slope (gradient) for the acceleration process in clockwise rotation (cw). The time given here is
to be implemented for a setpoint jump of 1000 rpm. That is to say, the drive follows the setpoint jump ramped up by 1000 revs in the time set here.
Parameter 0x1B: t ramp-down cw
Description: Parameter is to be seen and used as the ramp slope (gradient) for the braking process in clockwise rotation (cw). The time given here is to be
implemented for a setpoint jump of 1000 rpm. That is to say, the drive follows the setpoint jump ramped up by 1000 revs in the time set here.
Parameter 0x1C: t-ramp-up ccw
Description: Parameter is to be seen and used as the ramp slope (gradient) for the acceleration process in counter-clockwise rotation (ccw). The time given
here is to be implemented for a setpoint jump of 1000 rpm. That is to say, the drive follows the setpoint jump ramped down by 1000 revs in the time set
here.
Parameter 0x1D: t-ramp-down ccw
Description: Parameter is to be seen and used as the ramp slope (gradient) for the braking process in counter-clockwise rotation (ccw). The time given
here is to be implemented for a setpoint jump of 1000 rpm. That is to say, the drive follows the setpoint jump ramped down by 1000 revs in the time set
here.
