4 Technical Specifications
4.5 electronic properties
Inputs IN a, IN B
Properties Unit Value / Comment
Input level – PLC level
Low level V < 5
High level V > 15
Protection against polarity reversal and voltages V ≤ 30
if case of cable break – Logic level “0”
Input impedance k Ω 5.4
Input frequency kHz ≤ 10
Input dynamic (Tau) ms ≤ 0.1
Applied logic level – IN A = B = 0 = output stage switched off, FK 5
IN A or B = 1 = output stage switched on
Subject to change without notice
Inputs IN 1, IN 2
Properties Unit Value / Comment
Input level – PLC level
Low level V < 5
High level V > 15
Protection against polarity reversal and voltages V ≤ 30
if case of cable break – Logic level “0”
Input impedance k Ω 5.4
Maximum input frequency for command source via PWM / frequency kHz 15
Input dynamic (Tau) ms ≤ 0.1
Subject to change without notice
Outputs (PNP)
Properties Unit Value / Comment
Output level – High side driver dependent on U
Logic
(logic supply)
Low level V Open source
High level V > U
Logic
- 2
Protection against polarity reversal and voltages V ≤ 30
Output current / channel mA ≤ 100
Peak output current / channel A approx. 600 mA (thermally dependent)
Short-circuit proof – yes
Polarity reversal protection – no
Overload protected – yes (automatic thermal cut-out)
Output frequency @ I
out
= 100 mA kHz ≤ 1
