57
7 Parameterisation of the Operating Modes
7.21 Operating mode 55: IN a / B logic via IN 1, IN 2; IN a / IN B as release (enable)
NOTe
In order for the parameter to function, KP_H must be > 0.
Function IN 1: Emulation IN A.
Function IN 2: Emulation IN B.
Speed Current limit
IN A IN B IN 1 IN 2 Direction Value Type Value Function Comment
0 0 x x - 0 - - Free-wheeling No braking, no current feed
1 0 0 0 - 0 S P Free-wheeling No braking, no current feed
1 0 1 0 pos A1 S P N control
1 0 0 1 neg A1 S P N control
1 0 1 1 - 0 S P Stop Braking and stopping
0 1 0 0 - 0 S P Free-wheeling No braking, no current feed
0 1 1 0 pos A1 S P N control
0 1 0 1 neg A1 S P N control
0 1 1 1 - 0 S P Stop Braking and stopping
1 1 0 0 - 0 S P Free-wheeling No braking, no current feed
1 1 1 0 pos A1 S P N control
1 1 0 1 neg A1 S P N control
1 1 1 1 - 0 S P Stop Braking and stopping
Stop control = If KP_H > 0; brake and stop in the current position on changeover to IN A = IN B = 1 + Coasting rh, lh.
If KP_H = 0; brake and stop on changeover to IN A = IN B = 1, run speed to 0.
S = Static
P = Parameter
F = Freeze
D = Dynamic
x = Arbitrary value
