27
5 Installation
Pin assignment (D-SUB pin 9 pole):
Adapter electrically isolated
Pin Connection
1 n. c.
2 optional – CAN L bus cable
3 gND
4 RS485 +
5 n. c.
6 gND
7 optional – CAN H bus cable
8 RS485 –
9 n. c.
USB device drivers of the type “FTDI USB Serial Converter” are required for operation of the USB-CAN-RS485 adapter. In many cases these
are already available on the PC or can be installed using the files provided in the subdirectory of the “Kickstart PC-Software\USB-CAN-basic-
driver-files”. Detailed installation instructions (in English) for the operating systems Windows 7, Windows Vista and Windows XP are provided
as PDF files in the installation directory of the “Kickstart” PC software.
Scope of supply:
1 USB-CAN-RS485 adapter (incl. microSD memory card)
1 Screw terminal adapter board to the D-SUB 9 connection
1 USB connection cable to the PC.
5.9 Connection to the USB-CaN-RS485 adapter
• Connect the cable at Pin 10 (violet) with connection 4 (RS485 +) of the USB-CAN-RS485 adapter.
• Connect the cable at Pin 11 (grey/pink) with connection 8 (RS485 –) of the USB-CAN-RS485 adapter.
• Switch on the “Logic” voltage at the power supply unit.
• Start the “Kickstart” tool at the PC for parameterisation.
• Load an existing project (*.kickzip or *.kicktpl) or create a new project: *.kickpro.
