5 Installation

5.3 electrical connection

The connection cable for the VDC-3-49.15-K4 drive system is attached to the motor in the factory, no additional plugs are required for the
electrical connection and parameter setting.

The following is required for the electrical connection and parameter setting of the ECI-63.XX-K4 drive system:
1 Connection cable with 15 pin connector M16 (not for the Litz wire (stranded wire) variant of the ECI-63.XX-K4,

see Chapter 5.4.4 Harness

for Litz wire version ECI-63.XX-K4, page 25

).

1 ebm-papst USB-CAN-RS485 adapter (screw terminal adapter board to the D-SUB 9 connection, USB connection cable to the PC).
1 ebm-papst “Kickstart” PC software.

DaNgeR

Health hazard!
The drive systems are installed in design applications in which electrical and electromagnetic components are used.
These can affect pacemakers, metallic implants or hearing aids and cause severe personal harm.

f

Avoid the immediate vicinity, especially areas identified by the warning symbol

, if you have a pacemaker, metal

implants or wear a hearing aid.

NOTe

• The drive systems are built-in parts and do not have any electrical disconnecting switches.

• Connect the product to suitable electrical circuits only. Please note that the power supply units must have suitable

protection against regenerative voltage generated on the secondary side.

• When working on the drive system the system / machine must always be disconnected from the power supply and

secured against being switched back on again.

5.3.1 Safety check

Before connecting the drive system, check:

• Supply voltage and product voltage identical?

• Does the rating plate data match the connection data of the power supply unit?

• Connection cable suitable for the current intensity and the ambient conditions and area of use?
