7 Parameterisation of the Operating Modes
7.39 Operating mode 91: Operation via RS485; distance / speed
NOTe
In order for the parameter to function, KP_H must be > 0.
Function IN 1:
none
Function IN 2:
none
IN A or IN B are used as release (enable).
Speed run command
Speed
Current limit
IN A
IN B
IN 1
IN 2
Direction
Value
Type
Value
Function
Comment
0
0
x
x
-
0
-
-
Free-wheeling
No braking, no current feed
1
0
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
1
0
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
1
0
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
1
0
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
0
1
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
0
1
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
0
1
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
0
1
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
1
1
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
1
1
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
1
1
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
1
1
x
x
RS485
RS485
S
RS485
N control / distance
Speed / position run command
Stop control =
If KP_H > 0; brake and stop in the current position on changeover to IN A = IN B = 1 + Coasting rh, lh.
If KP_H = 0; brake and stop on changeover to IN A = IN B = 1, run speed to 0.
Position run command
Distance via RS485
Speed 0x3F; current via the distance see
S = Static
P = Parameter
F = Freeze
D = Dynamic
x = Arbitrary value
