106

10 Parameter Description

Parameter 0x8005: Current actual temperature of the printed circuit board

Description: The parameter contains the current actual temperature of the printed circuit board.

Parameter 0x8006: Current electrical current I

d

Description: The parameter contains the current electrical current I

d

, which is calculated within the Park / Clark transformation.

Parameter 0x8007: Current electrical current I

q

Description: The parameter contains the current electrical current Iq, which is calculated within the Park / Clark transformation.

Parameter 0x8008 Output OUT 1-OUT 3

Description: The parameter contains the statuses of the outputs in bits 0-3. If the outputs are read out, the software replies with the current statuses of the

outputs OUT1-OUT3.
If the output has previously been parameterised to „RS485 controlled“, the software accepts only the output statuses at the respective output, if they are

set.

Parameter 0x8009: Inputs IN A / IN B / IN 1 / IN 2

Description: The current statuses of inputs IN A / IN B / IN 1 and IN 2 can be read.

Parameter 0x800D: Analog input IN A1

Description: The digitised value of the analog input „IN A1“ can be read. Only the digitised voltage value is returned, not the interpreted setpoint or actual

value.

Parameter 0x800E: Analog input IN A2

Description: The digitised value of the analog input "IN A2" can be read. Only the digitised voltage value is returned, not the interpreted setpoint or actual

value.
