SmartPlate Installation, Operation & Maintenance Manual
APPENDIX A – MODBUS CONTROL AND COMMUNICATION
OMM-0069_0E AERCO International, Inc.  100 Oritani Dr.  Blauvelt, NY 10913 Page 99 of 138
SP-100 Phone: 800-526-0288 PRI: 11/26/2013
DIAGNOSTIC ALARMS - continued
DISPLAY MEANING WHAT TO DO`
E r r 2 Error 2: RAM self-test fail Return Controller for repair
E r r 3
Error 3: Watchdog fail Return Controller for repair
E r r 4
Error 4: Keyboard failure.
Stuck button or button was
pressed during power-up
Switch power off and then on, without
touching any of the controller buttons
E r r 5
Error 5: Faulty internal
communication
Check printed circuit board
interconnections. If the fault cannot be
cleared, return the controller for repair.
E r r 6
Digital filter chip faulty or
loose board inside controller
Return Controller for repair
E r r 7 PV ID failure Return Controller for repair
E r r 8
Module 1 ID failure
Faulty or loose module, or isolation
problem
E r r 9 Module 2 ID failure
Faulty or loose module, or isolation
problem
E r r A
Module 3 ID failure
Faulty or loose module, or isolation
problem
d C F DC output failure Return Controller for repair
O P E n
Secondary Input Missing or
Disconnected
This error may result from no power to the
flow meter (check for green power light on
rear of meter or 0-5V flowmeter signal
connections), or a disconnection of the
Molex connector between feedforward
sensor and the Eurotherm controller.
A3.1. CLEARING HARDWARE ERROR (Hw.Er) DISPLAY
To clear a Hardware Error and reset the Temperature Controller, proceed as follows:
3. Display flashes Hw.Er after adding or removing comm. bd.
4. Simultaneously press the Page ( ) and Scroll ( ) buttons on the Temperature
Controller.
5. Using the Up (▲) arrow button, change the password to “8”.
6. Simultaneously press the Page ( ) and Scroll ( ) buttons again and observe the
Temperature Controller display. The top line will display “8” and the bottom line will display
“NO”.
7. Press the Up (▲) arrow button to toggle the display from “NO” to “YES”.
8. Simultaneously press the Page ( ) and Scroll ( ) buttons to “Reset” the
Temperature Controller and clear the Hardware Error.
