CHAPTER 2. INSTALLATION
2.1 INTRODUCTION
All of the SmartPlate Water Heater Models are shipped fully assembled and ready for
installation. Therefore, installation will consist of the following tasks:
Unpack SmartPlate from its shipping container
Position and secure the SmartPlate Water Heater at the site.
Connect the hot boiler water piping to the SmartPlate
Connect the domestic hot water (DHW) piping to SmartPlate
Connect external AC power to the SmartPlate ECS/SP Control Box
If required, connect Modbus control wiring to the Temperature Controller in the ECS/SP
Control Box
2.2 RECEIVING AND UNPACKING SMARTPLATE
Each SmartPlate Water Heater is shipped as a single crated unit. The packaged shipping
weight will vary from 380 to 1220 pounds depending on the model ordered. The unit must be
moved with the proper equipment (forklift, pallet jack, etc.) to avoid possible injury to personnel
or damage to the shipping container or unit. The shipping carton should be inspected for
damage incurred during transit prior to signing the bill of lading.
NOTE
AERCO is not responsible for lost or damaged freight. The freight
carrier must be notified immediately of any damage detected.
Unpack the SmartPlate Water Heater from its shipping container taking care not to damage the
unit when cutting away the packaging material. Remove the bolts securing the SmartPlate to its
shipping skid. Perform a complete visual inspection of the unit to ensure there is no evidence of
damage.
2.3 SITE SELECTION AND PREPARATION
Ensure that the site selected for installation of the SmartPlate Water Heater includes the
following:
Access to AC input power at 120 VAC/60 Hz or 220 VAC/50 Hz, single phase
Close proximity to the boiler to be used as the heating fluid (hot water) source
If applicable; access to Modbus Network wiring within the prescribed wire lengths (see
paragraph 2.5.
2.3.1 Installation Clearances
The heater must be installed with the prescribed clearances for service as shown in Figure 2-1.
the minimum clearance dimensions recommended by AERCO are listed below. However, if
