SmartPlate Installation, Operation & Maintenance Manual

CHAPTER 4 – ADJUSTMENT

OMM-0069_0E

AERCO International, Inc.

 100 Oritani Dr.  Blauvelt, NY 10913

Page 25 of 138

SP-100

Phone: 800-526-0288

PRI: 11/26/2013

CHAPTER 4. ADJUSTMENT

4.1 INTRODUCTION

This Chapter provides the adjustment procedures for the 3-Way Control Valve, MXG-461 and
the SmartPlate Electronic Control System (ECS/SP).

Prior to shipment, from AERCO, all MXG-461 Control Valve Actuators are adjusted (auto-
stroked) to ensure that they properly position the Control Valve from the fully-open to the fully-
closed positions. In addition, the ECS/SP is adjusted to the Setpoint Temperature specified on
the Sales Order.

It is recommended that the following procedures be performed to the extent necessary, prior to
placing the SmartPlate Water Heater into operation. Also, the applicable procedures MUST be
performed following replacement of the MXG-461 Control Valve or ECS/SP components to
ensure that all parameters are properly set.

CAUTION

As a precaution, ensure that all heating fluid hot boiler water
shutoff valves are fully closed prior to performing any of the
following adjustment procedures.

4.2 SMARTPLATE 3-WAY CONTROL VALVE, MXG-461 ADJUSTMENT

The 3-Way Control Valves, (Siemens, MXG-461) used on all SmartPlate Models are powered
by 24 VAC. For SmartPlate applications, each 3-Way Valve is controlled by a 0 to 10 VDC
signal received from the Temperature Controller (Eurotherm 2408) contained in the ECS/SP. A
0 VDC signal places the Control Valve in the full bypass position from port B to port AB (valve
shaft up). A 10 VDC signal places the Control Valve in the full flow position from port A to port
AB (valve shaft down).

4.2.1 Control Valve Calibration and Status Indications

The control Valve Actuators are self-calibrating for all Valve sizes. Therefore, simply proceed as
follows to automatically adjust the Valve Actuator:

1. Refer to Figure 4-1 and loosen the two (2) captive screws securing the cover on the

Electronics Module of the MXG-461 Control Valve.
