AERCO SmartPlate User Manual
Page 90
SmartPlate Installation, Operation & Maintenance Manual
CHAPTER 8 – CORRECTIVE MAINTENANCE
Page 90 of 138
AERCO International, Inc.
100 Oritani Dr. Blauvelt, NY 10913
OMM-0069_0E
PRI: 11/26/2013
Phone: 800-526-0288
SP-100
ECS/SP CONTROL BOX ASSEMBLY 69096 PARTS LIST
ITEM QUANTITY PART
NO.
DESCRIPTION
1 1
65082
TRANSFORMER, X075CBA, 120/240 TO 24
VAC
2
1
64008-[ ]
TEMPERATURE INDICATOR CONTROLLER
3
3
64056
OVER-TEMP SWITCH/TEMP INDICATOR
4 3
60003 ON/OFF
SWITCH
6
1
65087
TERMINAL BLOCK, 12-POSITION (TB-2)
7
1
65008
TERMINAL BLOCK, 20-POSITION (TB-1)
12
1
63047
AC WIRE HARNESS
13 1
63048 CONTROL
WIRING
HARNESS
15 1
63009-3
EXTERNAL
HARNESS
18
AS REQ’D
SEE TABLE A COMMUNICATIONS BOARD
22 5
62003 PLUG
23 1
69098 FUSE
30
1
72010-1
LABEL, AERCO LABEL
40
1
72010-16
LABEL, WATER HEATER
TABLE A – COMMUNICATIONS BOARD OPTIONS
PART NUMBER
DESCRIPTION
64009-1
RS232 COMMUNICATIONS
BOARD
64009-2
RS485 COMMUNICATIONS
BOARD
