SmartPlate Installation, Operation & Maintenance Manual
APPENDIX D – SMARTPLATE DRAWINGS
OMM-0069_0E
AERCO International, Inc.
100 Oritani Dr. Blauvelt, NY 10913
Page 123 of 138
SP-100
Phone: 800-526-0288
PRI: 11/26/2013
1.5 " PIPING ASSY. PARTS FOR SP‐23/SP‐33
Item # Qty Part #
Description
15
1
27033‐2
REPLACEMENT TUBE & ADAPTOR, 1‐1/2"
16
2
93029
1/4" MNPT x 3/16" OD COMPRESSION FITTING
17
1
99042‐1
THERMOCOUPLE, SINGLE ELEMENT
18
1
92047‐2
CONTROL VALVE: 1.5"
19
2
92006‐7
VALVE: BALL BRASS 1‐1/2" NPT
20
1
90047‐3
PIPE NIPPLE: SS SCH. 1.5" X 3" LG.
21
4
93159
COUPLING: QUIK FLEX 2"
22
1
22098‐2
1.5" TUBE‐VICTAULIC ASSY: 14.38" LG
23
1
97023‐2
TEE: PROPRESS: 1.5" X 1.5" X 1.5"
24
3
97022‐2
STRAIGHT ADAPTER: 1.5" TUBE x 1.5" MNPT
25
1
93247
HEX REDUCING BUSHING: 3/4" MNPT x 1/4" FNPT
26
1
59188
PROCESS FILTER GAUGE w/FITTING
27
2
97020
1/4" MNPT x 1/4" OD COMPRESSION FITTING
28
2
91043
GAGE TUBE
29
1
92049
COMBINATION BALL VALVE & STRAINER: 1 1/2" NPT
30
1
22100‐1
SPOOL PIECE: 1" TUBE X FREEDOM FLANGE
31
1
41023
MANIFOLD: INTAKE
32
1
92070
VALVE: AIR BLEEDER 1" NPT
33
1
22098‐1
1.5" TUBE‐VICTAULIC ASSY: 7.00" LG
34
1
97023‐6
TEE: PROPRESS: 1.5" X 1.5" X 1"
35
1
91045‐6.38
COPPER TUBE: 1.5" X 6.38" LG
36
1
97024‐2
TEE: PROPRESS: 1.5" X 3/4 NPT" X 1.5"
37
1
92060
VALVE: 3/4 BOILER DRAIN
38
1
92051‐1.5
BALL VALVE: 1.5" w/ SIDE PORT
39
1
22097
TUBE w/ FREEDOM FLG ASSY
40
1
69095‐1
PUMP: RECIRCULATING 60 Hz (See Items 48–52 for spare parts)
1
69095‐2
PUMP: RECIRCULATING 50 Hz (See Items 48–52 for spare parts)
41
1
12610‐9‐8
REDUCING BUSHING: 2" NPT X 1.5" NPT: SS
42
1
99042‐2
THERMOCOUPLE, DUAL ELEMENT
43
1
88012
O‐RING (set of 10) FOR BALL VALVE TRAINER COMBO 1‐1/2"
44
2
61018
BOILER WATER OUTLET SENSOR (Not Shown on Drawing)
45
1
65092
VALVE ELECTRONIC MODULE
46
2
99085
STRAINER SCREEN
47
1
90047‐9.75
PIPE NIPPLE: SS SCH: 1.5" X 9.75" LG.
48
1
89011‐1
CIRCULATOR FLANGE GASKET SET (Pump Spare Part)
49
1
89011‐2
CIRCULATOR CASING O‐RING (Pump Spare Part)
50
1
89011‐3
CIRCULATOR CAPACITOR 60 Hz (Pump Spare Part)
51
1
89011‐4
CIRCULATOR CAPACITOR 50 Hz (Pump Spare Part)
52
1
89011‐5
CIRCULATOR CARTRIDGE ASSEMBLY (Pump Spare Part)
53
22083
BALL VALVE & STRAINER COMBO 2” + DIFF GAUGE
54
27032‐2
DIFFERENTIAL GAGE ASSEMBLY KIT
AERCO
International, Inc.
Blauvelt, NY 10913
SmartPlate – Single Wall Part List
07/15/2013
29116-TAB rev E (PL-A-160)
Sheet 2 of 6
