SmartPlate Installation, Operation & Maintenance Manual
APPENDIX D – SMARTPLATE DRAWINGS
Page 130 of 138
AERCO International, Inc.
100 Oritani Dr. Blauvelt, NY 10913
OMM-0069_0E
PRI: 11/26/2013
Phone: 800-526-0288
SP-100
1.5 " PIPING ASSY. PARTS FOR SPDW‐23/SPDW‐32
Item # Qty Part #
Description
23
1
27033‐2
REPLACEMENT TUBE & ADAPTOR, 1‐1/2"
24
2
93029
1/4" MNPT x 3/16" OD COMPRESSION FITTING
25
1
99042‐1
THERMOCOUPLE, SINGLE ELEMENT
26
1
92047‐2
CONTROL VALVE: 1.5"
27
2
92006‐7
VALVE: BALL BRASS 1‐1/2" NPT
28
1
90047‐3
PIPE NIPPLE: SS SCH. 1.5" X 3" LONG
29
4
93159
COUPLING: QUIK FLEX 2"
30
1
22098‐2
1.5" TUBE‐VICTAULIC ASSY: 14.38" LONG
31
1
97023‐2
TEE: PROPRESS: 1.5" X 1.5" X 1.5"
32
3
97022‐2
STRAIGHT ADAPTER: 1.5" TUBE x 1.5" MNPT
33
1
93247
HEX REDUCING BUSHING: 3/4" MNPT x 1/4" FNPT
34
1
59188
PROCESS FILTER GAUGE w/FITTING
35
2
97020
1/4" MNPT x 1/4" OD COMPRESSION FITTING
36
2
91043
GAGE TUBE
37
1
92049
COMBINATION BALL VALVE & STRAINER: 1 1/2" NPT
38
1
22100‐1
SPOOL PIECE: 1" TUBE X FREEDOM FLANGE
39
1
41023
MANIFOLD: INTAKE
40
1
92070
VALVE: AIR BLEEDER 1" NPT
41
1
22098‐1
1.5" TUBE‐VICTAULIC ASSY: 7.00" LONG
42
1
97023‐6
TEE: PROPRESS: 1.5" X 1.5" X 1"
43
1
91045‐6.38
COPPER TUBE: 1.5" X 6.38" LONG
44
1
97024‐2
TEE: PROPRESS: 1.5" X 3/4 NPT" X 1.5"
45
1
92060
VALVE: 3/4 BOILER DRAIN
46
1
92051‐1.5
BALL VALVE: 1.5" w/ SIDE PORT
47
1
22097
TUBE w/ FREEDOM FLG ASSY
48
1
69095‐1
PUMP: RECIRCULATING 60 Hz (See Items 56–60 for spare parts)
1
69095‐2
PUMP: RECIRCULATING 50 Hz (See Items 56–60 for spare parts)
49
1
12610‐9‐8
REDUCING BUSHING: 2" NPT X 1.5" NPT: SS
50
1
99042‐2
THERMOCOUPLE, DUAL ELEMENT
51
1
88012
O‐RING (set of 10) FOR BALL VALVE TRAINER COMBO 1‐1/2"
52
2
61018
BOILER WATER OUTLET SENSOR (Not Shown on Drawing)
53
1
65092
VALVE ELECTRONIC MODULE
54
2
99085
STRAINER SCREEN
55
1
90047‐16.25 PIPE NIPPLE: SS SCH: 1.5" X 16.25" LONG
56
1
89011‐1
CIRCULATOR FLANGE GASKET SET (Pump Spare Part)
57
1
89011‐2
CIRCULATOR CASING O‐RING (Pump Spare Part)
58
1
89011‐3
CIRCULATOR CAPACITOR 60 Hz (Pump Spare Part)
59
1
89011‐4
CIRCULATOR CAPACITOR 50 Hz (Pump Spare Part)
60
1
89011‐5
CIRCULATOR CARTRIDGE ASSEMBLY (Pump Spare Part)
61
22083
BALL VALVE & STRAINER COMBO 2” + DIFF GAUGE
62
27032‐2
DIFFERENTIAL GAGE ASSEMBLY KIT
AERCO
International, Inc.
Blauvelt, NY 10913
SmartPlate – Double Wall Part List
07/15/2013
29117-TAB rev C (PL-A-161)
Sheet 3 of 7
