Smartplate – single wall part list – AERCO SmartPlate User Manual
Page 125
SmartPlate Installation, Operation & Maintenance Manual
APPENDIX D – SMARTPLATE DRAWINGS
OMM-0069_0E
AERCO International, Inc.
100 Oritani Dr. Blauvelt, NY 10913
Page 125 of 138
SP-100
Phone: 800-526-0288
PRI: 11/26/2013
2.0 " PIPING ASSY. PARTS FOR SP‐45/SP‐69/SP‐150
Item # Qty Part #
Description
55
1
27033‐1
REPLACEMENT TUBE & ADAPTOR, 1‐1/2"
56
2
93029
1/4" MNPT x 3/16" OD COMPRESSION FITTING
57
1
99042‐1
THERMOCOUPLE, SINGLE ELEMENT
58
1
92047‐1
CONTROL VALVE: 2"
59
2
123540
VALVE: BALL 2" FULL PORT
60
2
90046‐3
NIPPLE: 2" NPT 304 SS
61
4
93159
COUPLING: QUIK FLEX 2"
62
1
22099‐2
2" TUBE‐VICTAULIC ASSY: 14.13" LG
63
1
97023‐1
TEE: PROPRESS: 2" X 2" X 2"
64
3
97022‐1
STRAIGHT ADAPTER: 2" TUBE x 2" MNPT
65
1
93262
HEX REDUCING BUSHING: 1" MNPT x 1/4" FNPT
66
1
59188
PROCESS FILTER GAUGE w/FITTING
67
2
97020
1/4" MNPT x 1/4" OD PASS THROUGH COMPRESSION TUBE FITTING
68
2
91043
GAGE TUBE
69
1
92063
COMBINATION BALL VALVE & STRAINER: 2" NPT
70
1
22100‐1
SPOOL PIECE: 1" TUBE X FREEDOM FLANGE
71
1
41023
MANIFOLD: INTAKE
72
1
92070
VALVE: AIR BLEEDER 1" NPT
73
1
22099‐1
2" TUBE‐VICTAULIC ASSY: 6.69" LG
74
1
97023‐5
TEE: PROPRESS: 2" X 2" X 1"
75
1
91044‐6.19
COPPER TUBE: 2" X 6.19" LONG
76
1
97024‐1
TEE: PROPRESS X NPT: 2" X 3/4 NPT" X 2"
77
1
92060
VALVE: 3/4 BOILER DRAIN
78
1
92051‐2
BALL VALVE: 2" NPT w/ SIDE PORT: BRONZE
79
1
22097
TUBE w/ FREEDOM FLANGE
80
1
69095‐1
RECIRCULATING PUMP, 60 Hz (See Items 87‐91 for spare parts)
1
69095‐2
RECIRCULATING PUMP, 50 Hz (See Items 87‐91 for spare parts)
81
1
90046‐8.0
NIPPLE, 2" X 8.0” LONG
82
1
99042‐2
THERMOCOUPLE, DUAL ELEMENT
83
1
88013
O‐RING (set of 10) FOR BALL VALVE TRAINER COMBO 2"
84
2
61018
BOILER WATER OUTLET SENSOR (Not shown on drawing)
85
1
69092
VALVE ELECTRONIC MODULE
86
2
99085
STRAINER SCREEN
87
1
89011‐1
CIRCULATOR FLANGE GASKET SET (Pump Spare Part)
88
1
89011‐2
CIRCULATOR CASING O‐RING (Pump Spare Part)
89
1
89011‐3
CIRCULATOR CAPACITOR (Pump Spare Part) 60 hZ
90
1
89011‐4
CIRCULATOR CAPACITOR (Pump Spare Part) 50 hZ
91
1
89011‐5
CIRCULATOR CARTRIDGE ASSEMBLY (Pump Spare Part)
92
22084
BALL VALVE & STRAINER COMBO KIT 2” + DIFF GAUGE
93
27032‐1
DIFFERENTIAL GAGE ASSEMBLY KIT
AERCO
International, Inc.
Blauvelt, NY 10913
SmartPlate – Single Wall Part List
07/15/2013
29116-TAB rev E (PL-A-160)
Sheet 4 of 6
