Page 63
SmartPlate Installation, Operation & Maintenance Manual
CHAPTER 8 – CORRECTIVE MAINTENANCE
OMM-0069_0E
AERCO International, Inc.
100 Oritani Dr. Blauvelt, NY 10913
Page 63 of 138
SP-100
Phone: 800-526-0288
PRI: 11/26/2013
SECTION II SMARTPLATE DOUBLE-WALL HEAT EXCHANGER MODELS
8.5 DOUBLE-WALL HEAT EXCHANGER MAINTENANCE
The maintenance procedures for SmartPlate Double-Wall Models (Figure 8-5) include
procedures for:
Cleaning (in-place or by disassembly)
Opening/Closing Heat Exchanger and Removal/Replacement of Plate
Replacement of Gaskets
Heat Exchanger Replacement
The procedures listed above are provided in paragraphs 8.6 through 8.9.
DRAIN
VALVE
BOILER
WATER
INLET
BOILER
WATER
OUTLET
DHW
OUTLET
COLD
WATER
INLET
ISOLATION
BALL VALVES
ISOLATION
BALL VALVES
MANIFOLD
AIR
VENT
HEAT
EXCHANGER
ECS/SP
CONTROL
BOX
RECIRC.
PUMP
Figure 8-5. SmartPlate Double-Wall (Model SPDW113)
