Page 62
SmartPlate Installation, Operation & Maintenance Manual
CHAPTER 8 – CORRECTIVE MAINTENANCE
Page 62 of 138
AERCO International, Inc.
100 Oritani Dr. Blauvelt, NY 10913
OMM-0069_0E
PRI: 11/26/2013
Phone: 800-526-0288
SP-100
SUPPORT
FRAME
HAND HOLE
CUTOUT
(BOTH SIDES)
HEAT
EXCHANGER
(HX)
MOUNTING
ATTACHMENT
4 PLACES
(VIEW “A - A”)
A
A
SUPPORT
FRAME
HEAT EXCHANGER
MOUNTING TAB
(4 PLACES)
FLAT
WASHER
HEX HEAD
BOLT
HEAT
EXCHANGER
REAR VIEW
VIEW “A - A”
HEX
NUT
Figure 8-4. Heat Exchanger Mounting Details
