SmartPlate Installation, Operation & Maintenance Manual
CHAPTER 7 – TROUBLESHOOTING
OMM-0069_0E AERCO International, Inc.  100 Oritani Dr.  Blauvelt, NY 10913 Page 55 of 138
SP-100 Phone: 800-526-0288 PRI: 11/26/2013
Table 7-3A. Dynamic Temperature Control Settings for SmartPlate Single- Water Heaters
Unit Size
(SP or
SPDW)
Boiler Water
Temp
(Tbw)
Feed
Forward
Parameter
(FFPb)
Proportional
Band 1
(Pb)
*Integral 1
(I1)
*Derivitive 1
(D1)
Proportional
Band 2
(Pb2)
*Integral 2
(I2)
*Derivitive 2
(D2)
*Gain Schedule
Cutoff Temp
(Gsch)
SP23,
SPDW23
<=180 °F -40 40 20 5 30 20 5 145
<=200 °F -40 50 20 5 40 20 5 145
<=220 °F -50 50 20 5 40 20 5 145
SP33,
SPDW32
<=180 °F -50 50 20 5 40 20 5 145
<=200 °F -50 60 20 5 50 20 5 145
<=220 °F -60 60 20 5 50 20 5 145
SP45,
SPDW42
<=180 °F -60 60 20 5 50 20 5 145
<=200 °F -60 70 20 5 60 20 5 145
<=220 °F -70 70 20 5 60 20 5 145
SP69,
SPDW61
<=180 °F -80 60 20 5 55 20 5 145
<=200 °F -80 70 20 5 65 20 5 145
<=220 °F -95 70 20 5 65 20 5 145
SP150,
SPDW113
<=180 °F -100 60 20 5 60 20 5 145
<=200 °F -100 70 20 5 70 20 5 145
<=220 °F -120 70 20 5 70 20 5 145
