background image

CHAPTER 7 8454

7-4

D569-W02 May-2003

3. TIGHTENING TORQUE

Tightening torque

Brake shaft

Mounting bolt of parking brake shaft

Mounting nut of brake cam lever

Mounting bolt of brake case

Mounting nut of brake case

Mounting nut of brake rod

367.8 ~ 431.6 N·m

37.5 ~ 44.0 kgf·m

271.2 ~ 317.8 lbf·ft

23.5 ~ 27.4 N·m

2.4 ~ 2.8 kgf·m

17.3 ~ 20.2 lbf·ft

123.6 ~ 147.1 N·m

12.6 ~ 15.0 kgf·m

91.1 ~ 108.5 lbf·ft

77.5 ~ 90.2 N·m

7.9 ~ 9.2 kgf·m

57.1 ~ 66.5 lbf·ft

77.5 ~ 90.2 N·m

7.9 ~ 9.2 kgf·m

57.1 ~ 66.5 lbf·ft

48.0 ~ 55.9 N·m

4.9 ~ 5.7 kgf·m

35.4 ~ 41.2 lbf·ft
