6.6 CLEARANCE BETWEEN CLUTCH
PEDAL SHAFT AND CLUTCH
PEDAL BUSHING
A. Measure the outer diameter of clutch pedal shaft.
B. Obtain the clearance by measuring the inner diam-
eter of clutch pedal bushing.
C. If the measurement is out of the allowable limit,
replace it.
Clearance between clutch pedal shaft
and clutch pedal bushing. Factory spec.
Allowable limit
0.007 ~ 0.101 mm
0.0003 ~ 0.00 4 in.
0.4 mm
0.0157 in.
Outer diameter of clutch pedal shaft Factory spec. 24.980 ~ 24.993 mm
0.9834 ~ 09839 in.
Inner diameter of clutch pedal bushing Factory spec. 25.000 ~ 25.081 mm
0.9842 ~ 09874 in.
