FRONT AXLE
5-5 D569-W03 June-2003
Differential pinion to differential side
gear shim
Spiral bevel pinion shaft
(Pinion shaft only)
Spiral bevel pinion shaft to spiral bevel gear
12 T bevel gear to 16 T bevel gear shim
13 T bevel gear to 39 T bevel gear shim
Backlash
Thickness
Turning Torque
Backlash
Backlash
Thickness
Backlash
Thickness
0.1 ~ 0.3 mm
0.004 ~ 0.012 in.
0.1 mm
0.0039 in.
0.1mm
0.0078 in.
0.2 mm
0.0157 in.
1.6 mm
0.0630 in.
1.27 ~ 1.667 N·m
0.13 ~ 0.17 kgf·m
0.94 ~ 1.23 lbf·ft
0.2 ~ 0.3 mm
0.0078 ~ 0.0118 in.
0.15 ~ 0.35 mm
0.0059 ~ 0.0138 in.
0.1 mm
0.0039 in.
0.2 mm
0.0078 in.
0.4 mm
0.0157 in.
0.8 mm
0.03149 in.
1.0 mm
0.0393 in.
0.15 ~ 0.35 mm
0.0059 ~ 0.0138 in.
0.1 mm
0.0039 in.
0.2 mm
0.0078 in.
0.4 mm
0.0157 in.
0.8 mm
0.03149 in.
1.0 mm
0.0393 in.
1.2 mm
0.0472 in.
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Item Factory Specification Allowable Limit
