BRAKE
7-3 D569-W02 May-2003
25 ~ 40 mm
0.984 ~ 1.574 in.
Less than 5 mm
0.20 in.
0.007 ~ 0.101 mm
0.00027 ~ 0.00397 in.
24.980 ~ 24.993 mm
0.9834 ~ 0.9839 in
25.000 ~ 25.081 mm
0.9842 ~ 0.9874 in.
-
20.9 ~ 21.1 mm
0.8228 ~ 0.8307 in.
4.6 ~ 4.8 mm
0.181 ~ 0.189 in.
2.54 ~ 2.66 mm
0.100 ~ 0.1047 in.
-
-
0.4 mm
0.0197 in.
-
-
0.3 mm
0.012 in.
20.6 mm
0.8110 in.
4.0 mm
0.1574 in.
2.0 mm
0.0787 in.
2. SPECIFICATIONS
Brake pedal
Right and left
Brake pedal shaft to bushing
Brake pedal shaft
Bushing (brake pedal)
Cam plate 1
Cam plate 1 and ball
Brake disc
Plate
Item
Free play
Difference
Clearance
O.D.
I.D.
Flatness
Height
Thickness
Thickness
Factory Specifications Allowable Limit
1. TROUBLESHOOTING
Uneven braking force
Brake drags
Poor braking force
Symptom
- Brake pedal play unevenly adjusted
- Brake disc worn
- Cam Plate warped
- Brake pedal play too small
- Cam plate return spring weaken or broken
- Brake pedal return spring weaken or broken
- Brake camshaft rusted
- Brake pedal play excessive
- Brake disc worn
- Cam plate warped
- Brake camshaft or lever damaged
- Brake camshaft or lever damaged
Provable Causes
Adjust
Replace
Replace
Adjust
Replace
Replace
Repair
Adjust
Replace
Replace
Replace
Change
Solution
