40

Montaggio

(da fucile imballato)

Componenti confezione (fig. 1):
a) gruppo calcio-carcassa-otturatore-astina
b) gruppo canna-culatta

Procedura di montaggio

1) Inserire a fondo la manetta di armamen-

to nel corpo otturatore (fig. 2).

2) Svitare il cappellotto fissaggio astina e

toglierlo dal tubo serbatoio (figg. 3-4).

Assembly

(from packaged gun)

Components of the package (fig. 1):
a) stock-receiver-bolt-fore-end unit
b) barrel-breech unit

Assembly procedure

1) Insert completely the cocking lever into

the breech bolt unit (fig. 2).

2) Unscrew the fore-end cap and remove

from the magazine tube (figs. 3-4).

Montage

(fusil emballé)

Pièces de l’emballage (fig. 1):
a) groupe crosse-carcasse-obturateur-devant
b) groupe canon-culasse

Marche à suivre pour le montage

1) Introduire la manette d’armement à fond

dans le corps de l’obturateur (fig. 2).

2) Dévisser le capuchon de fixation du de-

vant et l’enlever du magasin (figs. 3-4).

1

2

b

a
