54 Alarms & Alerts Welch Allyn Propaq CS Vital Signs Monitor
Customize alarm limits based on patient’s current vital
signs
To quickly set all alarm limits, from the Main Menu press SETUP, ALARMS, STAT SET.
The monitor turns on all alarms and calculates new alarm limits based on the patient’s
current vital sign values. Make sure that the new limits are appropriate for the patient.
STAT SET limit calculations
a
a. New alarm limits calculated by STAT SET cannot be outside the allowable alarm limit range. If a new limit is calculated to be above
or below the allowable alarm limit range, it defaults to the maximum or minimum alarm limit allowed for that vital sign.
Vital sign If the patient’s
vital sign value is
Then the calculated
new lower limit is
Then the calculated
new upper limit is
Heart Rate HR
≤ 99
100 - 250
HR
≥ 251
HR x 0.8
HR - 20
Unchanged HR x 1.2
HR + 20
250
Pulse Rate PR
≤ 99
PR
≥ 100
PR x 0.8
PR - 20 PR x 1.2
PR + 20
Invasive
Pressure Inv Prs
≤ 25
26 - 99
Inv Prs
≥ 100
Inv. Pressure - 5
Inv. Pressure x 0.8
Inv. Pressure - 20 Inv. Pressure + 5
Inv. Pressure x 1.2
Inv. Pressure + 20
NIBP NIBP
≤ 25
26 - 99
NIBP
≥ 100
NIBP - 5
NIBP x 0.8
NIBP - 20 NIBP + 5
NIBP x 1.2
NIBP + 20
Respiration
Rate/Breath
Rate RR/BR
≤ 25
26 - 99
RR/BR
≥ 100
RR/BR - 5
RR/BR x 0.8
RR/BR - 20 RR/BR + 5
RR/BR x 1.2
RR/BR + 20
Temperature Temp
≥ 0°C
Temp - 0.5 Temp + 0.5
SpO
2
SpO
2
≥ 0%
SpO
2
- 5
(min. limit 50%)
100% (adult and pediatric mode)
SpO
2
+ 5 (neonate mode)
ETCO
2
ETCO
2
≥ 0 mmHg
ETCO
2
≥ 2.0 (% or kPa)
ETCO
2
- 5 mmHg
(min. 15 mmHg)
ETCO
2
- 0.7 (% or kPa)
(min 2.0% or 2.0 kPa)
ETCO
2
+ 10 mmHg
ETCO
2
+ 1.4 (% or kPa)
INCO
2
INCO
2
≥ 0 mmHg
INCO
2
≥ 0 (% or kPa)
Not affected by STAT SET INCO
2
+ 5 mmHg
INCO
2
+ 0.7 (% or kPa)
Apnea Delay Not affected by STAT SET
WARNING If a patient’s vital sign value falls outside of the upper or lower alarm
range limit, STAT SET turns off the alarm and the alarm limit except for the
following:
1. The lower alarm limits for SpO
2
and ETCO
2
are not turned off by STAT SET.
2. If HR/PR ALARM LIMITS in the Settings window is set to CANNOT TURN
OFF, STAT SET affects HR/PR alarm limits as follows:
HR/PR PATIENT VALUE DISPLAY UPPER LIMIT LOWER LIMIT
Overrange +++ Maximum Unchanged
Underrange - - - Unchanged Minimum
Indeterminate ??? Unchanged Unchanged
