106 Reference Welch Allyn Propaq CS Vital Signs Monitor
Alarms specifications
Nurse Call specifications
Nurse Call cable specifications
This cable (008-0634-XX) must be customized by a biomedical technician to connect to
the local Nurse Call system.
Characteristic Specification
Indicators Flashing red alarm bell light: patient alarm(s)
Continuously on red alarm bell light: patient alarm silenced or suspended
Flashing yellow crossed-alarm light: equipment alert
Continuously on yellow crossed-alarm light: one or more patient alarm limit(s) off
Tone Frequency 900 Hertz
Tone Patterns Apnea: 1 second on, 1 second off
Patient alarm: 1 second on, 2 seconds off
Equipment alert: 1 second on, 4 seconds off
Selectable Tone Volume Low, Medium, High
Limits Settable on all parameters
Control Automatic preset or manual settings
Alarm Priority Highest priority: Apnea, then patient alarms
Lowest priority: Equipment alerts
Alarm on Tachycardias Most tachycardias will alarm in less than 8 seconds. These include AAMI 3.1.2.1 part f.
waveforms. Certain multifocal tachycardias may initially alarm as “low rate.”
Apnea delay setting Adult/Ped = 6, 10, 15, 20, 25, 30 seconds
Neonate = 6, 10, 15, 20 seconds
Alarm Holdoff Time Period a
a. To help minimize false alarms, the monitor briefly delays or “holds off” triggering alarms for limit violations for these vital signs. After
the alarm holdoff period begins, if the monitor detects that the patient’s vital sign has returned to acceptable limits, the monitor
cancels the alarm holdoff. The next time a vital sign limit is violated, the monitor starts a new holdoff period.
HR/PR = 3 seconds (except NIBP PR)
SpO
2
= 10 seconds
RR/BR = 5 seconds
Audio Alarm Holdoff with
Acuity When a Propaq CS monitor in Adult or Pediatric Mode is connected to an Acuity System,
the audio alarms at the bedside monitor can be delayed up to 4 minutes and 15 seconds.
The delay time is selected in Acuity software at the time of Acuity installation. Visual
alarm indications and Nurse Call alarm are not delayed.
Characteristic Specification
Maximum switch current 1 A
Maximum switch voltage 30 V ac/dc
Isolation 1500 Vrms
Alarm relay Energized during apnea alarm or patient alarm
a
a. Pressing the Silence/Reset Alarm key or SILENCE silences the Nurse Call alarm for 90 seconds.
Customized cable b (008-0634-XX); see
below.
b. Refer to Welch Allyn Products and Accessories to order the cable.
One end is a 4-pin plug compatible with the monitor Nurse Call connector; the
other end must be customized to connect to the local Nurse Call system.
