102 Reference Welch Allyn Propaq CS Vital Signs Monitor
Pulse oximetry (SpO
2
) specifications for Nellcor SpO
2
Characteristic Specification a
a. When performing SpO
2
monitoring, the monitor SpO
2
channel may not (in rare instances) initially detect a damaged SpO
2
sensor or
extension cable (as described in EN865:1997, Section 51.109), but may simply display a flat line and no numerics. If this occurs, try
connecting a new SpO
2
sensor (and extension cable, if needed) and restart the monitor to resume normal monitoring.
Saturation (% SpO
2
)
Range
Resolution
Alarm Limits
b
b. Minimum difference between upper and lower alarm limits is 2%.
0% to 100%
1%
52% to 100% (upper)
50% to 98% (lower)
Probe Accuracy c (saturation levels
between 70% and 100%, 28° to 42°C)
Adult/Pediatric
Neonatal
c. Refer to the Welch Allyn Products and Accessories guide (810-0409-XX) for accuracy specifications for all Nellcor SpO
2
probes
recommended for use.
Digit accuracy: ±2 counts
Digit accuracy: ±3 counts
Pulse Rate
Range
Alarm Limits
25 to 250 beats per minute
27 to 250 beats per minute (upper)
25 to 248 beats per minute (lower)
Pulse Rate Accuracy ±3 beats per minute
Alarm Hold-Off Time Period 10 seconds; resets if the sensor reports levels within limits before 10
seconds elapses
Circuitry Microprocessor controlled
Automatic self-test of oximeter when powered on
Automatic setting of default parameters
Automatic alarm messages
Electrosurgery interference suppression Yes
Sensor Compatibility Compatible only with Nellcor sensors listed in the Welch Allyn Products and
Accessories booklet.
Sensor LEDs
RED Wavelength
INFRARED (IR) Wavelength 660 nm (nominal)
890 nm (nominal)
Sensor Energies (Radiant Power)
Electrical Power
Optical Power
52.5 mW max.
15 mW max.
