98 Reference Welch Allyn Propaq CS Vital Signs Monitor
Invasive pressure specifications
Characteristic Specification
Transducer Type Strain-gauge resistive bridge, or HP quartz (with HP Option). a
a. Transducers with 40 µV/V/mmHg sensitivity are not compatible.
Transducer Excitation Impedance Range 200 to 2000
Ω
Transducer sensitivity 5 µV/V/mmHg
Excitation Voltage 4.85 V Pulsed dc @ 181 Hz
b
b. Duty factor depends on transducer impedance. For 200 to ~900 Ω, duty factor is ≅
11%. Above ~900 Ω, the duty factor increases to
≅
91%.
Connector ITT-Cannon plug MS3106F-14S-6P Std.
Hewlett-Packard compatible 12-pin connector (optional).
Bandwidth Digital filtered, dc to 20 Hz
Zero Drift ±1 mmHg without transducer drift
Zero Adjustment ±200 mmHg including transducer offset
Numeric Accuracy ±2 mmHg or 2% of reading, whichever is greater, plus transducer error
Pressure range -30 to 300 mmHg
Pulse range 25 to 250 beats per minute
c
c. At pulse rates exceeding 250 beats per minute, refer to the IBP waveforms on the display or printout to determine systolic and
diastolic pressures.
IBP Alarm Limit Ranges All patient modes
Systolic, Diastolic, Mean
-30 to 300 mmHg
Leakage Current Meets ANSI/AAMI risk (leakage) requirements
Electrosurgery interference suppression Included in all models
