Register Map for WebPak 3000 Drives 8-9
N10:218 DIG OUT 1 CONTACT TYP P.410 Config 0 = NORMAL OPEN
1 = NORMAL CLOSED
N10:219 DIG OUT 2 SELECT P.411 Config 0 = LEVEL DETECTOR OUT 1
1 = LEVEL DETECTOR OUT 2
2 = At speed
3 = In current limit
4 = Drive ready
5 =
CURRENT MEM COMMAND
6 = UNDERWIND COMMAND
7 = TENSION COMMAND
8 = STALL TENSION COMMAND
9 = SLACK TAKE UP COMMAND
10 = DIAMETER RESET TP
11 = ARMATURE BRIDGE POL
12 = FIELD ECONOMY ACTIVE
13 = NETW COMM STATUS
14 = NETW IN REG 1
15 = NETW IN REG 2
16 = NETW IN REG 3
17 = SPEED PROFILER ENABLE
18 = DIAMETER CALC ENABLE
N10:220 DIG OUT 2 CONTACT TYP P.412 Config 0 = NORMAL OPEN
1 = NORMAL CLOSED
N10:221 LINE SPEED SIG TYPE P.100 Config 0 = 0 to 10 V
1 = +/-10 V
2 = 4 to 20 mA
3 = 10 to 50 mA
N10:222 TENSION SETPT SIG TYP P.413 Config 0 = 0 to 10 V
1 = +/-10 V
2 = 4 to 20 mA
3 = 10 to 50 mA
N10:223 ANLG OUT 3 SIG TYPE P.419 Config 0 = 0 to 10 V
1 = +/-10 V
2 = 4 to 20 mA
3 = 10 to 50 mA
Table 8.1 – File N10:x (Drive Read/Write Parameters) for WebPak 3000 Drives (Continued)
File
Address Parameter Name
Parameter
Number Type Scale
