Register Map for FlexPak 3000 Drives
7-13
N11:20
ANALOG
MANUAL
REFERENCE
P.192
Analog Manual mode reference value, after scaling
N11:21
SPD
SOURCE
SELECT
OUT
P.193
Selected speed source value
N11:22
ANALOG
MAN
TRIM
REF
P.194
Trim reference value when analog input used for trim
N11:23
DRAW
PERCENTAGE
OUT
P.196
Product of selected trim reference and
TRIM
RANGE
(P.109)
N11:24
TRIM
OUTPUT
P.197
Present value added to
SPD
SOURCE
SELECT
OUT
(P.193)
N11:25
SPEED
RAMP
INPUT
TP
P.198
Speed reference value immediately before S-curve
ramp
N11:26
SPEED
RAMP
OUTPUT
P.199
Speed reference value immediately after S-curve
ramp
N11:27
IR
COMPENSATION
TP
P.290
Value subtracted from
ARMATURE
VOLTAGE
(P.289)
N11:28
ANALOG
TACH
FEEDBACK
P.291
Analog tachometer value, after scaling
N11:29
PULSE
TACH
FEEDBACK
P.292
Pulse encoder value, after scaling
N11:30
CURRENT
COMPOUND
TP
P.293
Value subtracted from
SPEED
RAMP
OUTPUT
(P.199)
N11:31
JOG
RAMP
OUTPUT
P.294
Jog reference value immediately after jog ramp
N11:32
SPD
LOOP
ERROR
P.297
Difference between
SPD
LOOP
REFERENCE
(P.295) and
SPD
LOOP
FEEDBACK
(P.296)
N11:33
SPD
LOOP
LAG
OUTPUT
P.298
Value immediately after speed loop forward path lag
N11:34
AC
LINE
VOLTAGE
P.392
Measured AC line voltage (RMS value)
N11:35
AC
LINE
PERIOD
P.393
Measured AC line period (
µsec)
N11:36
ARMATURE
BRIDGE
POL
P.394
0 =
OFF
(forward bridge active)
1 =
ON
(reverse bridge active)
N11:37
J
18
ARM
I
FB
RESISTOR
P.395
1 = 15 ohm, 2 = 20 ohm, 3 = 30 ohm, 4 = 39 ohm
N11:38
CML
REFERENCE
P.396
Reference value to the CML after rate and amplitude
limiting
N11:39
CML
FEEDBACK
(5
OR
10
MS
UPDATE
)
P.397
CML feedback value after conditioning and scaling
N11:40
CML
ERROR
P.398
Difference between
CML
REFERENCE
(P.396) and
CML
FEEDBACK
(P.397)
N11:41
ARMATURE
DELTA
P.399
Present armature firing angle, in
µsec
N11:42
DIG
IN
0
P.490
Digital input 0 (terminal 12 on regulator board); Brush
Wear, Jog Speed Select, or OCL Enable
N11:43
FREQ
IN
P.491
Frequency input (terminals 39, 40, 41 on the
I/O Expansion board)
N11:44
ANLG
IN
1
P.492
Analog input 1 (terminals 50, 51 on the I/O Expansion
board)
N11:45
ANLG
IN
2
P.493
Analog input 2 (terminals 52, 53 on the I/O Expansion
board)
N11:46
DIG
IN
1
P.495
Digital input 1 (terminal 59 on the I/O Expansion
board) Preset A
Table 7.2 – File N11:x (Drive Display Data (Read Only)) for FlexPak 3000 Drives (Continued)
File
Address
Parameter Name
Parameter
Number
Description
