Register Map for FlexPak 3000 Drives 7-15
N11:73 NETW COMM STATUS P.908 0 = NOT ACTIVE , 1 = ACTIVE
N11:74 NETW TYPE & VERSION P.909 TV.VV:
T = Network type
1, 2 = AutoMax, Profibus, InterBus
4 = DeviceNet
5 = ControlNet
V.VV = Network board firmware version number
N11:75 NETW DROP NUMBER P.900 Internal network drop number
N11:76 First Fault Code --- Fault code of the first fault that occurred following the
last fault reset
N11:77 Fault Log Count --- Number of faults in the fault log
N11:78 Fault Log 0 --- Fault log value 1
N11:79 Fault Log 1 --- Fault log value 2
N11:80 Fault Log 2 --- Fault log value 3
N11:81 Fault Log 3 --- Fault log value 4
N11:82 Fault Log 4 --- Fault log value 5
N11:83 Fault Log 5 --- Fault log value 6
N11:84 Fault Log 6 --- Fault log value 7
N11:85 Fault Log 7 --- Fault log value 8
N11:86 Fault Log 8 --- Fault log value 9
N11:87 Fault Log 9 --- Fault log value 10
N11:88 Last Alarm Code --- Alarm code of the most recent alarm
0 = no active alarms
N11:89 Alarm Log Count --- Number of alarms in the alarm log
N11:90 Alarm Log 0 --- Alarm log value 1
N11:91 Alarm Log 1 --- Alarm log value 2
N11:92 Alarm Log 2 --- Alarm log value 3
N11:93 Alarm Log 3 --- Alarm log value 4
N11:94 Alarm Log 4 --- Alarm log value 5
N11:95 Alarm Log 5 --- Alarm log value 6
N11:96 Alarm Log 6 --- Alarm log value 7
N11:97 Alarm Log 7 --- Alarm log value 8
N11:98 Alarm Log 8 --- Alarm log value 9
N11:99 Alarm Log 9 --- Alarm log value 10
N11:100
|
N11:172
Reserved --- Reserved
Table 7.2 – File N11:x (Drive Display Data (Read Only)) for FlexPak 3000 Drives (Continued)
File
Address Parameter Name
Parameter
Number Description
