8-2 ControlNet Network Communication Option Board For Use With FlexPak 3000 and WebPak 3000 DC Drives
N10:28 WINDER CORE DIA 2 P.824 Tunable 1 = 1.00 in
N10:29 WINDER CORE DIA 3 P.825 Tunable 1 = 1.00 in
N10:30 DIAMETER ACCEL RATE P.823 Tunable 1 = 0.001 in/s
N10:31 DIAMETER DECEL RATE P.827 Tunable 1 = 0.001 in/s
N10:32 DIAMETER REGISTER P.874 Tunable 1 = 1.000
N10:33 DIAMETER / TAPER SELECT P.870 Tunable 0 = DIAMETER , 1 = TAPER RANGE
N10:34 OCL PROP TRIM GAIN P.812 Tunable 1 = 0.001
N10:35 OCL INVERT ENABLE P.815 Tunable 0 = DISABLE , 1 = ENABLE
N10:36 OCL PARALLEL OFFSET P.810 Tunable
N10:37 POS LEADLAG LOW FREQ P.231 Tunable 1 = 0.01 rad/s
N10:38 POS LEADLAG RATIO P.232 Tunable
N10:39 POS RAMP TIME P.233 Tunable 1 = 0.1 s
N10:40 POS PI LEAD FREQ P.234 Tunable 1 = 0.01 rad/s
N10:41 POS PI LIMIT P.235 Tunable
N10:42 POS PI PROP GAIN P.236 Tunable 1 = 0.01
N10:43 POSITION CROSS OVER P.239 Tunable 1 = 0.01 rad/s
N10:44 POSITION REFERENCE P.240 Tunable
N10:45 POSITION ZETA P.242 Tunable 1 = 0.01
N10:46 STORAGE P.857 Tunable 1 = 0.1 feet
N10:47 TEN RAMP TIME P.833 Tunable 1 = 0.1 s
N10:48 TEN FDBK LL LOW FREQ P.835 Tunable 1 = 0.01 rad/s
N10:49 TEN FDBK LL RATIO P.836 Tunable
N10:50 TEN LEADLAG SELECT P.837 Tunable 0 = LEAD / LAG , 1 = BYPASS , 2 = LAG / LEAD
N10:51 TEN OUT LL LOW FREQ P.838 Tunable 1 = 0.01 rad/s
N10:52 TEN OUT LL RATIO P.839 Tunable
N10:53 TEN PI LEAD FREQ P.840 Tunable 1 = 0.01 rad/s
N10:54 TEN PI PROP GAIN P.841 Tunable 1 = 0.001
N10:55 TEN FDBK LL BYPASS P.845 Tunable 0 = OFF , 1 = ON
N10:56 TENSION FDBK MAX P.851 Tunable
N10:57 TENSION FDBK MIN P.852 Tunable
N10:58 TENSION PI LIMIT P.853 Tunable
N10:59 SLACK TENSION PI LIM P.318 Tunable 1 = 0.1%
N10:60 STALL TENSION FIX P.134 Tunable
N10:61 STALL TENSION PERCENT P.135 Tunable 1 = 0.1%
N10:62 TAPER ENABLE P.858 Tunable 0 = DISABLE , 1 = ENABLE
N10:63 TAPER REGISTER P.860 Tunable 1 = 0.001
N10:64 TAPER SET REGISTER P.861 Tunable 1 = 0.1%
N10:65 TENSION SETPOINT P.854 Tunable
N10:66 TENSION SETPOINT SEL P.855 Tunable 0 = REGISTER , 1 = ANALOG
Table 8.1 – File N10:x (Drive Read/Write Parameters) for WebPak 3000 Drives (Continued)
File
Address Parameter Name
Parameter
Number Type Scale
