7-2 ControlNet Network Communication Option Board For Use With FlexPak 3000 and WebPak 3000 DC Drives
N10:27 OCL PI PROP GAIN P.808 Tunable 1 = 0.01
N10:28 OCL PI LEAD FREQ P.809 Tunable 1 = 0.01 rad/s
N10:29 OCL PI POSITIVE LIMIT P.810 Tunable 1 = 1% of TOP SPEED (P.011)
N10:30 OCL PI NEGATIVE LIMIT P.811 Tunable 1 = 1% of TOP SPEED ( P.011)
N10:31 OCL TRIM RANGE P.812 Tunable 1 = 1% of TOP SPEED (P.011)
N10:32 OCL REFERENCE SELECT P.800 Tunable 0 = REGISTER
1 = ANALOG IN 1
2 = ANALOG IN 2
3 = FREQUENCY IN
4 = NETW IN REG 1
5 = NETW IN REG 2
6 = NETW IN REG 3
N10:33 OCL REF REGISTER P.801 Tunable 1 = 1/4095
N10:34 OCL REF RAMP TIME P.802 Tunable 1 = 0.1 s
N10:35 OCL REF ROUNDING P.803 Tunable 1 = 1%
N10:36 ENHANCED FLD VOLT ADJ P.500 Tunable
N10:37 FIELD ECONOMY DELAY P.501 Tunable 1 = 1 min
N10:38 FIELD ECONOMY REF P.511 Tunable 1 = 1% of MOTOR HOT FLD AMPS (P.510)
N10:39 FIELD REF REGISTER P.513 Tunable 1 = 1/4095 of MOTOR HOT FLD AMPS (P.510)
N10:40 FIELD PI PROP GAIN P.514 Tunable 1 = 0.01
N10:41 FIELD PI LEAD FREQ P.515 Tunable 1 = 0.01 rad/s
N10:42 FLD FEEDBACK GAIN ADJ P.516 Tunable 1 = 0.001
N10:43 FLD WEAKEN THRESHOLD P.518 Tunable 1 = 1/4095 MOTOR RATED ARM VOLTS (P.009)
N10:44 FLD WEAKEN PROP GAIN P.519 Tunable 1 = 0.01
N10:45 FLD WEAKEN LEAD FREQ P.520 Tunable 1 = 0.01
N10:46 NETW COMM LOSS SELECT P.901 Tunable 0 = FAULT
1 = USE LAST REF
2 = USE TRMBLK REF
3 = USE TRMBLK CNTL
N10:47 NETW OUT REG 1 SELECT P.902 Tunable
N10:48 NETW OUT REG 2 SELECT P.903 Tunable
N10:49 NETW OUT REG 3 SELECT P.904 Tunable
N10:50 RAMP STOP DECEL TIME P.018 Tunable 1 = 0.1 s
N10:51 STOP SPEED THRESHOLD P.113 Tunable 1 = 1 RPM
N10:52 STOP MODE SELECT P.114 Tunable 0 = RAMP
1 = CURRENT LIMIT
2 = COAST / DB
N10:53 JOG SPEED 1 P.012 Tunable 1 = 1 RPM
N10:54 JOG SPEED 2 P.017 Tunable 1 = 1 RPM
N10:55 JOG ACCEL / DECEL TIME P.013 Tunable 1 = 0.1 s
N10:56 TRIM REF REGISTER P.107 Tunable 1 = 0.1%
Table 7.1 – File N10:x (Drive Read/Write Parameters) for FlexPak 3000 Drives (Continued)
File
Address Parameter Name
Parameter
Number Type Scale
