7-10 ControlNet Network Communication Option Board For Use With FlexPak 3000 and WebPak 3000 DC Drives
N10:195 FREQ OUT SELECT P.425 Config 0 = CML FEEDBACK
1 = CML REFERENCE
2 = CML ERROR
3 = SPD LOOP FEEDBACK
4 = SPD LOOP REFERENCE
5 = SPD LOOP ERROR
6 = SPD LOOP OUTPUT
7 = SPEED RAMP OUTPUT
8 = SPEED RAMP INPUT TP
9 = SPD SOURCE SELECT OUT
10 = TRIM OUTPUT
11 = ARMATURE VOLTAGE
12 = ANALOG TACH FEEDBACK
13 = PULSE TACH FEEDBACK
14 = ZERO
15 = FULL SCALE
16 = POWER OUTPUT
17 = OCL REFERENCE
18 = OCL RAMP OUTPUT
19 = OCL FEEDBACK
20 = OCL OUTPUT
21 = FIELD REFERENCE
22 = FIELD FEEDBACK
23 = NETW IN REG 1
24 = NETW IN REG 2
25 = NETW IN REG 3
N10:196 FREQ OUT ZERO P.426 Config 1 = 1 kHz
N10:197 FREQ OUT FULL SCALE P.427 Config 1 = 1 kHz
N10:198 DIG IN 0 SELECT P.428 Config 0 = BRUSH WEAR INPUT
1 = JOG SPEED SELECT
2 = OCL ENABLE
N10:199 LEVEL DETECT 1 SELECT P.602 Config 0 = CML FEEDBACK
1 = SPD LOOP FEEDBACK
2 = SPD RAMP OUTPUT
3 = SPD RAMP INPUT TP
4 = SPD SOURCE SELECT OUT
N10:200 LEVEL DETECT 2 SELECT P.605 Config 0 = CML FEEDBACK
1 = SPD LOOP FEEDBACK
2 = SPD RAMP OUTPUT
3 = SPD RAMP INPUT TP
4 = SPD SOURCE SELECT OUT
N10:201 Spd Loop Pi Init Sel --- Config 0 = ZERO
1 = SPD LOOP PI INIT VAL
2 = ANALOG MAN TRIM REF
N10:202
|
N10:273
Reserved --- --- Reserved (future parameter expansion)
Table 7.1 – File N10:x (Drive Read/Write Parameters) for FlexPak 3000 Drives (Continued)
File
Address Parameter Name
Parameter
Number Type Scale
