Register Map for FlexPak 3000 Drives 7-5
N10:82 METER OUT 2 SELECT P.405 Tunable 0 = CML FEEDBACK
1 = CML REFERENCE
2 = CML ERROR
3 = SPD LOOP FEEDBACK
4 = SPD LOOP REFERENCE
5 = SPD LOOP ERROR
6 = SPD LOOP OUTPUT
7 = SPEED RAMP OUTPUT
8 = SPEED RAMP INPUT TP
9 = SPD SOURCE SELECT OUT
10 = TRIM OUTPUT
11 = ARMATURE VOLTAGE
12 = ANALOG TACH FEEDBACK
13 = PULSE TACH FEEDBACK
14 = ZERO
15 = FULL SCALE
16 = POWER OUTPUT
17 = OCL REFERENCE
18 = OCL RAMP OUTPUT
19 = OCL FEEDBACK
20 = OCL OUTPUT
21 = FIELD REFERENCE
22 = FIELD FEEDBACK
23 = NETW IN REG 1
24 = NETW IN REG 2
25 = NETW IN REG 3
N10:83 ANLG OUT 1 GAIN ADJ P.420 Tunable 1 = 0.001
N10:84 ANLG OUT 2 GAIN ADJ P.422 Tunable 1 = 0.001
N10:85 LEVEL DETECT 1 THRESH P.603 Tunable 1 = 0.1% of selected source
N10:86 LEVEL DETECT 1 DELAY P.604 Tunable 1 = 0.1 s
N10:87 LEVEL DETECT 2 THRESH P.606 Tunable 1 = 0.1% of selected source
N10:88 LEVEL DETECT 2 DELAY P.607 Tunable 1 = 0.1 s
N10:89 PLL MAXIMUM ERROR P.308 Tunable 1 = 1 µsec
N10:90 TACH LOSS SCR ANGLE P.608 Tunable 1 = 1 deg
N10:91 TACH LEAD FLT THRESH P.227 Tunable 1 = 0.1% of TOP SPEED (P.011)
N10:92 TACH LEAD FLT DELAY P.228 Tunable 1 = 1 ms
N10:93 SELF TUNE FIELD RANGE P.218 Tunable 1 = 0.01
N10:94 SELF TUNE STABILITY P.219 Tunable
N10:95 SELF TUNE BRIDGE P.220 Tunable 0 = FORWARD , 1 = REVERSE
N10:96 OPEN SCR SENSITIVITY P.600 Tunable 1 = 1%
N10:97 OPEN SCR TRIP THRESH P.601 Tunable
N10:98 CLOCK FUNCTIONS --- Tunable Read = Elapsed time (hours) since last
power up
Write bit 0 = 1 Reset clock to zero; any
other value written has no effect.
Table 7.1 – File N10:x (Drive Read/Write Parameters) for FlexPak 3000 Drives (Continued)
File
Address Parameter Name
Parameter
Number Type Scale
