Register Map for WebPak 3000 Drives 8-5
N10:114 ANLG OUT 2 GAIN ADJ P.401 Tunable 1 = 0.001
N10:115 ANLG OUT 2 ZERO ADJ P.403 Tunable
N10:116 ANLG OUT 2 SELECT P.405 Tunable 0 = CML FEEDBACK
1 = CML REFERENCE
2 = CML ERROR
3 = SPD LOOP FEEDBACK
4 = SPD LOOP REFERENCE
5 = SPD LOOP ERROR
6 = SPD LOOP OUTPUT
7 = SPEED RAMP OUTPUT
8 = SPD RAMP INPUT TP
9 = ARMATURE VOLTAGE
10 = ANALOG TACH FEEDBACK
11 = ENCODER FEEDBACK
12 = SPD SOURCE SELECT OUT
13 = TRIM OUTPUT
14 = FIELD REFERENCE
15 = FIELD FEEDBACK
16 = TEN RAMP OUTPUT
17 = POS RAMP OUTPUT
18 = OCL PARALLEL OUT
19 = OCL OUTPUT
20 = Power out
21 =
NETW IN REG 1
22 = NETW IN REG 2
23 = NETW IN REG 3
24 = Zero
25 = Full scale
26 =
DANCER LOADING
27 = TENSION DEMAND
28 = TAPER PERCENT
29 = DIAMETER ANALOG
30 = INERTIA COMPENSATION
N10:117 ANLG OUT 2 FILTER EN P.407 Tunable 0 = DISABLE , 1 = ENABLE
N10:118 ANLG OUT 3 GAIN ADJ P.420 Tunable 1 = 0.001
N10:119 ANLG OUT 4 GAIN ADJ P.422 Tunable 1 = 0.001
N10:120 LEVEL REGISTER 1 P.603 Tunable
N10:121 LEVEL DETECT 1 DELAY P.604 Tunable 1 = 0.1 S
N10:122 LEVEL REGISTER 2 P.606 Tunable
N10:123 LEVEL DETECT 2 DELAY P.607 Tunable 1 = 0.1 s
N10:124 PLL MAXIMUM ERROR P.308 Tunable 1 = 1
µsec
N10:125 TACH LOSS SCR ANGLE P.608 Tunable 1 = 1 degree
N10:126 TACH LEAD FLT THRESH P.227 Tunable 1 = 0.1% of TOP SPEED (P.011)
N10:127 TACH LEAD FLT DELAY P.228 Tunable 1 = 1 ms
N10:128 SELF TUNE STABILITY P.219 Tunable
Table 8.1 – File N10:x (Drive Read/Write Parameters) for WebPak 3000 Drives (Continued)
File
Address Parameter Name
Parameter
Number Type Scale
