7-8 ControlNet Network Communication Option Board For Use With FlexPak 3000 and WebPak 3000 DC Drives
N10:186 DIG OUT 2 SELECT P.411 Config 0 = LEVEL DETECT 1 OUTPUT
1 = LEVEL DETECT 2 OUTPUT
2 = IN CURRENT LIMIT
3 = DRIVE READY
4 = NETW COMM STATUS
5 = NETW IN REG 1 ( BIT 0)
6 = NETW IN REG 2 ( BIT 0)
7 = NETW IN REG 3 ( BIT 0)
N10:187 DIG OUT 2 CONTACT TYP P.412 Config 0 = NORMAL OPEN
1 = NORMAL CLOSED
N10:188 ANLG AUTO SIGNAL TYPE P.100 Config 0 = 0 to 10 V
1 =
±10 V
2 = 4 to 20 mA
3 = 10 to 50 mA
N10:189 ANLG IN 1 SIG TYPE P.413 Config 0 = 0 to 10 V
1 =
±10 V
2 = 4 to 20 mA
3 = 10 to 50 mA
N10:190 ANLG OUT 1 SIG TYPE P.419 Config 0 = 0 to 10 V
1 =
±10 V
2 = 4 to 20 mA
3 = 10 to 50 mA
N10:191 ANLG OUT 1 SELECT P.418 Config 0 = CML FEEDBACK
1 = CML REFERENCE
2 = CML ERROR
3 = SPD LOOP FEEDBACK
4 = SPD LOOP REFERENCE
5 = SPD LOOP ERROR
6 = SPD LOOP OUTPUT
7 = SPEED RAMP OUTPUT
8 = SPEED RAMP INPUT TP
9 = SPD SOURCE SELECT OUT
10 = TRIM OUTPUT
11 = ARMATURE VOLTAGE
12 = ANALOG TACH FEEDBACK
13 = PULSE TACH FEEDBACK
14 = ZERO
15 = FULL SCALE
16 = POWER OUTPUT
17 = OCL REFERENCE
18 = OCL RAMP OUTPUT
19 = OCL FEEDBACK
20 = OCL OUTPUT
21 = FIELD REFERENCE
22 = FIELD FEEDBACK
23 = NETW IN REG 1
24 = NETW IN REG 2
25 = NETW IN REG 3
Table 7.1 – File N10:x (Drive Read/Write Parameters) for FlexPak 3000 Drives (Continued)
File
Address Parameter Name
Parameter
Number Type Scale
