Page 82

82
Publication IASIMP-QS015C-EN-P - August 2011
Chapter 4
ArmorStart Local Control Configuration
26. Click the Edit mode icon
to exit the editor.
If the logic fails verification, the following
dialog box appears.
27. Click OK.
You will return to the logic editor where
you can make the necessary changes and
revalidate the program.
Download Program to ArmorStart
1. Download the program to the ArmorStart
device by choosing Download from the
communication pull-down menu.
2. Click OK if the download is successful.
3. From the Communications menu, choose
Logic Enable On.
This will enable logic in the ArmorStart
device.
4. From the File menu choose File>Close.
