Faceplate Logix Integration
Chapter 5
ArmorStart Status Tags
Tag Names
Function
Corresponding ArmorStart Device Tag
Sts_DriveStatus_AtReference
Provides Status of Corresponding
ArmorStart device Tag
Inp_ArmorStart_xxx.AtReference
Sts_DriveStatus_Input0
Inp_ArmorStart_xxx.Input0
Sts_DriveStatus_Input1
Inp_ArmorStart_xxx.Input1
Sts_DriveStatus_Input2
Inp_ArmorStart_xxx.Input2
Sts_DriveStatus_Input3
Inp_ArmorStart_xxx.Input3
Sts_DriveStatus_Mon
Inp_ArmorStart_xxx._140Mon
Sts_DriveStatus_Ready
Inp_ArmorStart_xxx.Ready
Sts_DriveStatus_RunningFwd
Inp_ArmorStart_xxx.RunningFwd
Sts_DriveStatus_RunningRev
Inp_ArmorStart_xxx.RunningRev
Sts_DriveStatus_Tripped
Inp_ArmorStart_xxx.Tripped
Sts_DriveStatus_Warning
Inp_ArmorStart_xxx.Warning
Sts_OperatorModeEnabled
Indicates Operator Control is Active
N/A
Sts_ProgramModeEnabled
Indicates Program Control is Active
Val_OutputFreq
Provides Status of Corresponding
ArmorStart device Tag
Inp_ArmorStart_xxx.OutputFrequency
