Chapter 6
FactoryTalk View Integration
Add Equipment Status Faceplate
The ME Equipment Status Faceplate files let you quickly load and configure a summary display of
preconfigured status and diagnostic displays or faceplates for FactoryTalk View Machine Edition. The
Equipment Status Faceplate works in conjunction with individual device faceplates and provides a single
summary display of all the faceplates that may be configured for an application. You can configure up to nine
device faceplates to run with the Equipment Status faceplate and you can launch each device faceplate
directly from it.
This example shows the Equipment Status Faceplate that you can add to your specific hardware system
display. This faceplate is configured for three rows or three devices and provides overall status of the device,
up to four additional status values to be monitored, and can launch the individual device faceplates for more
detailed information.
TIP
This section is optional and necessary only if you intend to use the Equipment Status Faceplate. To skip this
section, go to
.
IMPORTANT
In order to use the Equipment Status faceplate into your application, you must have PanelView Plus
terminal that supports 800x600 window size.
