Publication 2727-UM001D-EN-P - March 2004

6-6 External Hardware Connections and Configuration

3. Set the communications parameters required by your barcode

reader. Refer to your barcode reader’s literature for the settings
required.

4. Check the box Use Barcode Wand.

5. Select Close Configuration Window or OK (in the upper right

corner) to save the settings and minimize the window to the
taskbar.

TIP

Selecting the Exit Application button closes the
window without saving the current settings and
deactivates the barcode reader.

TIP

Barcodes are read like keyboard entries directed to
the selected cursor position, followed by a carriage
return.
