Publication 2727-UM001D-EN-P - March 2004
3-10 General Tablet Operation and Configuration
Changing the Display
Orientation The screen display can be set for portrait (vertical) or landscape
(horizontal) orientation, depending on your preference.
Follow these steps to change the orientation of the screen display:
1. Tap on the Start button and select Settings, Control Panel from
the menu.
2. Double-tap on the Display icon to open the Display Properties
dialog box.
3. On the Background tab, tap the Landscape check box to select
or deselect the Landscape orientation.
4. Tap the Restart button.
Tap to clear writing/drawing
ScreenDraw Mode is active
Tap to save writing/drawing
Tap to display InkNote window
Tap to send writing to recognition program
Restart button
Landscape check box
TIP
The touch screen will automatically recalibrate so the
stylus works correctly with it. However, if you are
having problems selecting with the stylus, manually
calibrate the screen as instructed on page 3-17.
