Chapter 1, Hardware description, Hardware features – Rockwell Automation 2727-T7P30D1F MobileView Tablet T750 User Manual User Manual
Page 13: Hardware features -1, Chapter
1
Publication 2727-UM001D-EN-P - March 2004
Chapter
1
Hardware Description
Hardware Features
The MobileView Tablet is shown below. The hardware elements,
controls, indicators, and ports are described in the following pages.
MobileV
MobileView
RF Antenna
Stylus
Handstrap
Side View
Front View
Microphone
Start/Enter Button
Navigational
Arrow Buttons
Next, Previous,
Plus & Minus Buttons
Programmable
Battery Status
LEDs
Screen
Brightness
Screen
Contrast
Touch Screen
Speaker
Buttons
Notification Indicator LEDs
