Publication 2727-UM001D-EN-P - March 2004
3-4 General Tablet Operation and Configuration
Stylus
The stylus is used to input data and execute functions by touching the
screen. An audible click occurs when the screen is touched. The
following operations can be performed with the stylus:
•
Tap: one quick touch of the stylus to the screen. A tap is used to
press an on-screen button, select a menu item, press a key on
the keyboard, and other similar operations.
•
Right Mouse Click: press and hold the stylus on the screen for
more than one second. This simulates a right mouse click.
•
Double-tap: two taps on the screen, in quick succession.
Double-tapping is used on icons to display a window and with
certain application operations.
•
Drag: pressing the stylus lightly on the screen and moving it
across the screen. Dragging is used for gestures and to move
small windows. Most applications will fill the entire screen and
they cannot be sized or moved. Smaller windows, such as the
Keyboard, can be moved by holding the stylus on the title bar of
the Window and dragging it to a different location.
•
Writing or drawing: the stylus can be used to write or draw on
the screen. See ScreenDraw Mode on page 3-9 for more
information. Handwriting can also be used with CalliGrapher’s
handwriting recognition program. See Handwriting Recognition
on page 3-8 for more information.
For more information on using the stylus, see CalliGrapher’s on-line
Help.
TIP
To avoid losing the stylus, always keep it in the
Tablet’s stylus holder when it is not in use.
IMPORTANT
To avoid scratching or damaging the screen, never
use a pen, pencil or other sharp implement in place
of the stylus.
