Page 37

Publication 2727-UM001D-EN-P - March 2004
General Tablet Operation and Configuration 3-13
Quick Launch is shown in the text box next to each button
indicator.
3. To change the program associations, press the respective
Browse buttons.
4. Using the browse dialog box, select the program you want the
Quick Launch button associated with. In the example below,
Pocket Paint (ppaint.exe) is selected.
5. Press the OK button to enter your change into the edit box in
the Buttons dialog box. Repeat the process to change other
Quick Launch settings if desired.
Advanced Button Configuration
The Advanced button configuration allows you to associate any of the
programmable buttons with a variety of PC type key functions or
Quick Launch activations.
Follow these steps to make button associations:
1. Tap on the Start button and select Settings, Control Panel from
the menu.
2. Double-tap on the Buttons icon to open the Buttons dialog box
and then tap the Advanced button.
Selected program
TIP
To revert to the default button settings, press the
Load Defaults button in the Buttons dialog box.
