Publication 2727-UM001D-EN-P - March 2004
3-14 General Tablet Operation and Configuration
The left side of the Button Configuration window lists the
programmable buttons and button combinations. The right side
shows a list of functions or keystrokes that can be associated
with those buttons. When you select a button on the left, the
function associated with that button is highlighted. In the
example below, the first program button is associated with
Quick Launch 1.
3. Tap the button you want to reprogram, then tap the desired
function or keystroke from the “Keys” list. Tap OK.
4. To configure another button, tap the Advanced button again and
repeat the process until all the desired buttons are
reprogrammed.
Advanced button
Button list
Selected button
Key Function
Selected
association
Load Defaults
button
List
