Preface
P–5
Related Documentation
The following documents contain additional information concerning
Allen-Bradley products. To obtain a copy, contact your local Allen-Bradley
office or distributor.
For Read This Document Document Number
A description of important differences
between solid-state programmable
controller products and hard-wired
electromechanical devices
Application Considerations for
Solid-State Controls
SGI-1.1
An article on wire sizes and types for
grounding electrical equipment
National Electrical Code
Published by the National Fire Protection
Association of Boston, MA.
A complete listing of current
documentation, including ordering
instructions. Also indicates whether the
documents are available on CD-ROM or
in multi-languages.
Allen-Bradley Publication Index SD499
A glossary of industrial automation terms
and abbreviations Allen-Bradley Industrial Automation
Glossary
AG-7.1
The following conventions are used throughout this manual:
•
Bulleted lists such as this one provide information, not procedural steps.
•
Numbered lists provide sequential steps or hierarchical information.
•
Italic type is used for emphasis.
•
Text in this font indicates words that appear on the HHP display.
•
NEW
RUNG
T
Keypad icons, like the one at the left, match the key you
should press.
•
For operations that require you to press a sequence of keys, the keypad
icons are displayed horizontally on the page, with the resulting screen
shown beneath. For example:
MENU
I 6 7
LD
ENT
P 0 0 0
I / 6 0
•
If a character is flashing on the HHP display, it is shown unbolded (such
as the
P in the screen above).
•
For operations that require you to press two keys simultaneously, the
keypad icons are displayed side-by-side as shown here:
1
ESC
•
For operations that require you to press an arrow key, the
key you should press is shown bolded, such as the right
arrow key shown here.
Common Techniques Used in
this Manual
